DIN2093 Disc Spring: 400+ Standard Specifications for Reliable Elastic Support in Industrial Applications
Disc springs are essential for reliability in mining machinery, wind power equipment, rail transit, and precision instruments. Jiangsu Sunzo manufactures these springs strictly according to DIN2093 standards, offering a comprehensive specification system and stable performance, making them the preferred choice for clients across multiple industries.
Core Product Features
Full series coverage: Outer diameter 6600mm, thickness 0.237mm, with over 400 standard specifications to meet diverse requirements
Multimaterial systems: 51CrV4, 60Si2MnA, stainless steel, Inconel, etc., adaptable to various operating conditions
Customizable surface treatments: phosphating, Dacromet, Jumeite, Teflon, etc., to enhance corrosion and wear resistance
Accuracy assurance: Grade I/II precision is available, with critical dimensions strictly controlled within standard ranges.
Typical application areas
trade | application scenarios | disc spring function |
construction machinery | brake, clutch, buffer | energy absorption, reset, pre-tension |
Energy equipment | Wind power locking, nuclear power plant valves, high voltage switches | fault safety, pressure holding |
traffic | railway buffer, automobile gearbox | impact absorption and clearance compensation |
precision manufactured | Tool clamping and instrumentation | Accurate positioning and force control |
Quick Reference of Technical Parameters (Partial Specifications)
number | D（ unit ：mm） | d（ unit ：mm） | t（ unit ：mm） | H₀ (unit: mm) | Compression force (N) | Reduce force by 50% (unit: N) | Compression force (N) |
001 001 | 6.00 | 3.20 | 0.30 | 0.45 | 45.00 | 84.00 | 119.00 |
001 010 | 10.00 | 3.20 | 0.40 | 0.70 | 75.00 | 133.00 | 179.00 |
001 050 | 18.00 | 6.20 | 0.80 | 1.50 | 480.00 | 822.00 | 1,072.00 |
001 100 | 31.50 | 12.20 | 1.25 | 2.20 | 761.00 | 1,343.00 | 1,805.00 |
001 200 | 100.00 | 41.00 | 4.00 | 7.20 | 8,715.00 | 15,219.00 | 20,251.00 |
001 300 | 250.00 | 127.00 | 7.00 | 14.80 | 26,895.00 | 42,527.00 | 50,466.00 |
The full 400+ specification table is available for request from the technical team
Selection and Technical Consultation
Our engineers can help you:
Match the optimal specifications based on load, space, and stroke
Design of combination schemes for butt and lap joints
Recommended Materials and Surface Treatment Processes
Provide sample testing and data validation
Jiangsu Sunzo the selection of elastic element more simple and the application more reliable
SUNZO has it’s own researching and development team and test center, has participate in rule-making of the latest national industry standards and the international ISO standards for disc springs.
