Industrial Disc Spring Product Solution: Technical Parameters and Selection Comparison of Three Types of Professional Disc Spring
As a professional manufacturer of elastic components, Jiangsu Sunzo Industry provides a comprehensive range of disc spring products. Our disc springs are designed and manufactured in strict compliance with the GB/T 1972 national standard, while also meeting international standards such as DIN 2093. Below are our three core product categories, each optimized for specific industrial applications.
product orientation ：
The standard series disc springs are our most widely used product line, suitable for most general industrial applications, achieving a good balance between performance reliability and economy.
Technical features:
Material system: High-quality spring steel (60Si2MnA or 50CrVA) is used to ensure stable material properties.
Precision level: Offers two precision levels (Level I and Level II) to meet various assembly requirements.
Surface treatment: Standard phosphating treatment with anti-rust oil application for basic protection
Specifications: Outer diameter ranges from 8mm to 400mm, thickness from 0.5mm to 25mm.
Load accuracy: Within the ±10% tolerance range specified by national standards
Typical application:
Buffer and Shock Absorption of General Purpose Machinery
conventional bolt pre-tightening device
Medium-load clutch engagement
Reset element of valve actuator
product orientation ：
It is specially designed for heavy load, impact load and high preload requirement, and special optimization is made in material selection, heat treatment process and structure design.
Technical features:
Material strengthening: 50CrVA or higher strength 70Si2CVA material
Heat treatment process: An optimized quenching + tempering process is adopted to ensure the matching of core hardness and toughness.
Stress Control: Verification of Critical Point Stress Level by Finite Element Analysis
Fatigue Performance: Fatigue Life Design for High Cycle Count Applications
Load-bearing capacity: 1525% higher than the standard series for the same size
Typical application:
Mine machinery brake system (conform to JB/T 3812 standard)
buffer device for heavy press
pre-tightening mechanism of large wind power equipment
heavy duty vehicle clutch system
product orientation ：
It is specially developed for precision equipment which requires precise force control, small displacement accuracy and high consistency.
Technical features:
Dimensional accuracy: the key dimension tolerance is controlled within 50% of the national standard Ⅰ grade accuracy.
Consistency of force value: The force value deviation of products in the same batch is controlled within ±5%.
Surface treatment: Precision polishing or special coating is applied to reduce the friction coefficient
Heat Treatment Control: Protective Atmosphere Heat Treatment to Reduce Surface Decarburization
Testing criteria: Each product undergoes full-scale inspection and load testing.
Typical application:
Force Control of Precision Instrument
Accurate Displacement Mechanism of Medical Devices
Precise Positioning of Automation Equipment
aerospace support facility
We provide professional selection support services:
Provide detailed product technical specifications
Calculate required spring specifications
optimal product mix
Customized design based on specific operating conditions
Configuration recommendations for combination springs
Help resolve installation space limitations
Provide samples for actual operating condition testing
Assist in life test verification
Provide test data analysis and improvement suggestions
All products undergo rigorous quality control:
Raw material inspection: Each batch of materials undergoes chemical composition and mechanical property testing.
Process Control: Statistical Process Control (SPC) for Critical Processes
Factory inspection: Each product undergoes dimensional and load testing.
Traceability System: Establishing a Comprehensive Production Batch Traceability System
1. Manufacturing Experience: With over 20 years of professional expertise in disc spring production
2. Equipment Capabilities: Equipped with advanced CNC stamping machines and heat treatment production lines
3. Testing capability: Equipped with a comprehensive laboratory for material testing and product evaluation
4. Research and Development Capability: Continuous Product Optimization and Research on New Material Applications
Choose Jiangsu Sunzo Industry and you will get:
high-quality products that meet national and international standards
Professional technical consultation and selection support
Reliable supply guarantee and after-sales service
Continuous technical improvement and product optimization
