Load State and Operating Condition Load: Analysis of Core Causes for Disc Spring Failure

The stress state of disc springs during service and actual operating loads are the core determinants of their performance and reliability. Specifically, the precision of load matching, the comprehensive impact of dynamic loads, and the effective control of preload and working stroke are critical engineering parameters that directly determine the service life and functional integrity of disc springs.

I. Engineering Significance of Load Matching Degree and Failure Cases

The actual working load on disc springs must undergo rigorous calculation and verification, strictly confined within their material allowable stress range. Prolonged or sustained overload conditions can easily cause disc spring materials to exceed elastic limits, triggering irreversible plastic deformation. Such cumulative damage not only accelerates microscopic fatigue processes but also serves as a direct precursor to functional failure. For instance, in practical applications of mechanical sealing systems, accompanying disc springs experienced significant elastic relaxation and stiffness degradation due to chronic overloading operations. This ultimately led to complete failure of the sealing interface, resulting in severe fluid leakage issues.

II. Influence Mechanism and Damage Modes of Dynamic Loads

Most disc springs are designed for dynamic operating conditions, requiring continuous exposure to various dynamic forces including impact loads and cyclic alternating fatigue loads. High-amplitude instantaneous impact loads can easily induce microcracks in stress concentration zones of disc springs, potentially leading to sudden brittle fracture failure. Long-term cyclic fatigue loads, on the other hand, cause cyclic stress damage within the material. After a specific number of load cycles, fatigue cracks tend to initiate at weak points and gradually propagate, ultimately resulting in fatigue fracture of the disc spring.

III. Avoidance Strategies and Optimization Practices for Resonant Operating Conditions

Resonance represents a highly destructive condition under dynamic loading conditions. For instance, in vibration suppression systems for power equipment, disc spring assemblies used in such systems may experience severe resonance when the excitation frequency of their operating environment unexpectedly approaches the natural frequency of the springs themselves. This phenomenon causes rapid fracture failure of the discs within extremely short timeframes. Engineering practice demonstrates that systematic optimization of disc spring structural parameters (e.g., thickness and assembly configurations) or adjustment of system mounting stiffness to effectively avoid resonance frequency ranges constitutes a critical strategy for significantly reducing or even eliminating the adverse effects of resonance.
