DIN2093 Standard Disc Spring Full Series Product Technical Manual
Jiangsu Sunzo Spring Technology Co., Ltd., a leading domestic manufacturer of disc springs, provides a full range of DIN2093-compliant products. Our offerings span hundreds of specifications from micro to super-large, with applications in aerospace, automotive, construction machinery, petrochemical, and power energy sectors. Below is the complete DIN2093 standard disc spring specification table and selection guide.
Strictly adhering to international standards: All products are designed and manufactured in strict compliance with DIN2093 standards, while also meeting the requirements of the national standard GB/T 1972.
Diverse material options: Available in 1074,51CrV4, 60Si2Mn, 65Mn, SUS302, SUS304, SUS316,177PH, Inconel 718, Inconel X750, and other materials.
Extensive surface treatment options: Phosphating, Dacromet, Blue Finish, Polishing, Jumeite, Passivation, Teflon, and other surface treatment processes available.
Complete specification range: Product outer diameters from 6mm to 600mm, covering all DIN2093 standard specifications
Accurate force control: Provides load data at 25%,50%, and 75% compression levels, facilitating engineering design and selection.
The following are the complete DIN2093 standard disc spring specifications provided by Jiangsu Sunzo Spring. The table includes each model's outer diameter D, inner diameter d, thickness t, free height H₀, h₀/t ratio, and load values under different compression loads.
Due to the length of the parameter table, here are some representative specifications:
Product Parameter Data Table
Product Code | D（ unit ：mm） | d（ unit ：mm） | t（ unit ：mm） | H₀ (unit: mm) | h₀ (unit: mm) | Compress by 25% | Compress by 50% | Compress 75% | Weight (unit: kg/1000 tablets) |
001 001 | 6.00 | 3.20 | 0.30 | 0.45 | 0.15 | f0.04/F45 | f0.08/F84 | f0.11/F119 | 0.04 |
001 002 | 8.00 | 3.20 | 0.20 | 0.40 | 0.20 | f0.05/F12 | f0.10/F21 | f0.15/F26 | 0.06 |
001 003 | 8.00 | 3.20 | 0.30 | 0.55 | 0.25 | f0.06/F46 | f0.13/F79 | f0.19/F104 | 0.10 |
... | ... | ... | ... | ... | ... | ... | ... | ... | ... |
001 413 | 600.00 | 282.00 | 24.00 | 46.00 | 22.00 | f5.50/F413600 | f11.00/F701300 | f16.50/F905000 | 41,500.00 |
Note: For the complete specification sheet, please contact our technical department.
Based on the required working load of the equipment, refer to the table for the 75% compression load value of the corresponding model.
For safety, the working load should not exceed 80% of the 75% compression load.
Select the model with appropriate free height H₀ based on the axial height limit of the installation space.
The radial clearance is determined by the outer diameter D and inner diameter d, and must meet the technical requirements for the clearance between the guide component and the part.
Under normal operating conditions: 60Si2Mn or 51CrV4 is selected for its high cost-performance ratio.
Corrosive environment: SUS304 and SUS316 stainless steel are selected
High temperature conditions: Inconel 718 and Inconel X750 superalloys are selected.
High fatigue requirements: Select 51CrV4 with excellent fatigue performance
Parallel (series): Increase the total deformation while keeping the load constant
Laminated (parallel): Increased total load with unchanged deformation
Composite combination: simultaneous increase in load and deformation
The Jiangsu Sunzo Spring Technology Team provides the following professional services to clients:
Type selection calculation support: assists engineers in calculating the required disc spring specifications based on actual working conditions
Combination Scheme Design:Disc Spring Group Combination Scheme for Complex Application
Custom Development of Non-standard: Developing Non-standard Size and Performance of Disc Spring According to Special Needs
Failure Analysis Service: Professional Analysis and Improvement Suggestions for Field Failures
Sample testing support: Provide samples for actual operating condition verification tests
Certified to ISO 9001 Quality Management System
The product complies with the requirements of DIN2093 and GB/T 1972 standards.
Material certification and performance test reports are provided for each batch of products.
100% inspection of critical dimensions to ensure batch consistency
